Domino Vx150i Thermal Transfer Printer
Fast and Easy Coding on Flexible Packaging
The Domino Vx150i thermal transfer printer is the ideal solution for companies seeking simple, reliable, and fast coding and marking on flexible packaging.
With a 300 dpi print resolution and speeds of up to 6 prints per second, the Vx150i supports intermittent printing up to 75 mm. The extended ribbon length, combined with the cassette management system, enables longer production runs while reducing downtime.
Beyond flexible packaging coding, the integration of promotional codes and serialization enhances traceability and anti-counterfeiting measures.
By using QuickDesign software with the Domino Vx150i, you can minimize errors and control all coding operations from a single location, even across multiple production lines with different requirements. QuickDesign supports standard communication protocols and can be integrated into existing ERP systems.
Why Choose the Domino Vx150i Thermal Transfer Printer?
The Domino Vx150i is compatible with various ribbon types, ensuring sustainable and high-quality coding for flexible packaging to meet any production requirement.
With its compact dimensions, the Vx150i is easy to integrate into any production line, optimizing space and efficiency.
The Vx150i features customizable user access management, allowing personalized privileges to enhance security and prevent unauthorized modifications.
Technical Information
Domino printers are compliant and sold in over 100 countries worldwide. Certifications: CE, NRTL, CB, and FCC 47CFR Part. 15B.
Technical Specifications
| Intermittent Mode (IM) | Continuous Mode (CM) | |
|---|---|---|
| Printing Mode | ✓ | ✓ |
| Print Resolution | 300 dpi | 300 dpi |
| Printhead Width | 32 or 53 mm | 32 or 53 mm |
| Print Area (32/53 mm printhead) | 32×75 mm / 53×75 mm | 32×100 mm / 53×100 mm |
| Maximum Ribbon Length | 770 m (AR) | 770 m (AR) |
| Printing Speed | Up to 600 mm/sec | From 10 to 750 mm/sec |
| Maximum Print Frequency | 6 prints/sec | Prints/sec |
| Connectors | 3+1 USB, 1RJ45, 1 GPIO, 1 encoder | 3+1 USB, 1RJ45, 1 GPIO, 1 encoder |
| Supported Print Formats | EAN, GS1, UCC, QR Code, Data Matrix, Han Xin, ITF, Code 128, text, graphics, 1D, 2D codes etc. | EAN, GS1, UCC, QR Code, Data Matrix, Han Xin, ITF, Code 128, text, graphics, 1D, 2D codes etc. |
| Dimensions | 200 mm (W) x 160 mm (H) x 218 mm (D) | 200 mm (W) x 160 mm (H) x 218 mm (D) |
| Weight | 5.9 kg | 5.9 kg |
| Cartridge Weight | 0.9 kg (without ribbon) | 0.9 kg (without ribbon) |
| Fully Electric | No compressed air required | No compressed air required |
| Power Supply | 100 to 240 VAC, 50/60 Hz | 100 to 240 VAC, 50/60 Hz |
| Operating Temperature / Humidity | 5 to 40°C / 20% to 80% RH | 5 to 40°C / 20% to 80% RH |
| Ribbon Saving Modes | Economy, Retraction, Column | Economy, Retraction, Column, Mid Print Halt |
| Protocol | Dynamark | Dynamark |
| Function Pack (Optional) | Serialization, Advanced Security, Promotional Coding | Serialization, Advanced Security, Promotional Coding |
| Tablet Connection | Via Wi-Fi dongle | Via Wi-Fi dongle |
| PC Connection | Network cable | Network cable |
| TouchPad (Optional) | 7” TouchPad, Dimensions: Width 220 mm x Height 150 mm x Depth 30 mm, Multi-language support | 7” TouchPad, Dimensions: Width 220 mm x Height 150 mm x Depth 30 mm, Multi-language support |
| Support Frame (Optional) | Full range of support stands for all needs | Full range of support stands for all needs |
